Safe and Portable Home Elevator for Family

Name: Safe and Portable Home Elevator for Family
Brand: IBIJI LIFTS PVT. LTD.
Price: 1500000.0 INR
Availability: InStock

Price 1500000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Safe and Portable Home Elevator for Family Specification

Door Opening Size
700 mm x 2000 mm (WxH)

Inclination
Vertical

Car Dimension
900 mm x 1100 mm x 2100 mm (WxDxH)

Overhead Height
2500 mm

Voltage
220V / 380V

Pit Depth
150 mm

Machine Room Size
Not Required (Machine Room-less Design)

Usage
Residential, Family, Indoor, Villas

Noise Level
55 dB

Load Capacity
250 kg - 400 kg

Step Width
No Steps (Cabin/Platform Elevator)

Hoist Way Size
1200 mm x 1300 mm (WxD)

Material
other Sheet

Power Supply
Single Phase/Three Phase, 50Hz/60Hz

Speed
0.4 m/s to 0.5 m/s

Max. Lifting Height
12 meters

Max. Lifting Weight
400 kg

Mechanism Type
Other

Working Temperature
-10C to 50C

Control Device
Microcomputer Control System

Safety Device
Emergency Stop, Overload Sensor, Interlock & Alarm, Battery Backup

Capacity
1-4 Persons

Color/Finish
Customizable

Intercom
Integrated/Optional

Installation Time
1-3 Days

Flooring Option
Anti-slip PVC/Vinyl/Granite

Remote Monitoring
Optional

Door Type
Automatic/Manual Swing Door

Application
Home, Residential Apartments, Duplex, Villa

Control Panel
Touch Panel/Push Button

Emergency Operation
Automatic Rescue Device, Manual Lowering

Power Consumption
1.5 kW to 2.2 kW

Floor Indicator
LED Display

Cabin Lighting
LED Energy Saving Lights

Portability Feature
Designed for Easy Relocation & Installation

Safe and Portable Home Elevator for Family Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Kolkata

Supply Ability
1 Piece Per Week

Delivery Time
1 Week

Main Domestic Market
East India

About Safe and Portable Home Elevator for Family

The Stiltz Trio Wheelchair Lift is a smart, economical and sustainable home mobility solution which can fit a standard sized or manual wheelchair and is ideal for users with a walker or rollator. Our wheelchair elevator is an attractive alternative to a stair lift and allows you to live independently at home. The Stiltz range of wheelchair lifts offer a spacious and smooth travel experience and, most importantly, makes your home fully accessible with no section of your home off limits.

At Stiltz, we have been designing and manufacturing home elevators for over a decade and this experience shines through in the engineering and craftsmanship of each new product. The Stiltz Trio Wheelchair Lift is a game changer in the industry, as it combines cutting-edge technology without compromising on style. No detail is overlooked and every wheelchair lift includes convenient hold-to-run controls, a full height light curtain with fitted half height door and the option of a thru-car design allowing entry and exit from both sides avoiding awkward maneuvers.

It takes a maximum of just two days for one of our Authorized Dealers to install your wheelchair elevator before you can start to enjoy a whole new freedom and independence. The elevator is also useful for carry heavy objects or awkward items and can also carry three standing people. Once fitted, the Stiltz Trio Home Elevator simply plugs straight into a domestic power socket and is fully operational with no supporting walls needed. Spacious enough for a standard sized wheelchair, yet surprisingly compact with a footprint covering 15 sq ft, a Stiltz elevator preserves precious floorspace, while giving you access to all areas, at all times.

Stiltz Trio Wheelchair Elevator Range

Stiltz Trio Alta is a spacious and luxurious wheelchair-accessible home elevator designed to carry a full-sized wheelchair or three people. The combination of style and luxury has been perfectly balanced and the elevator has clear sides which enables it to blend seamlessly into the home and to make it even less intrusive the rails are cleverly and discreetly recessed behind the slightly wider entrance/exit.

Stiltz Trio Thru Car allows users to enter and exit from both sides of the elevator. This is made possible by the unique Stiltz dual rail technology. There is no other wheelchair home elevator of this kind on the market that is capable of different entry and exit points on different floors. It offers all the same features as the Trio Alta.

Stiltz Trio Wheelchair Elevator Benefits

Small Footprint

Smallest footprint of any wheelchair lift covers less than 15 sq ft surface area

Quiet to use

Fast Installation

Elevators are made up of modular sections standard installs take as little as one day

Uses Standard Electrical Outlet

Plugs into a standard dedicated 220v power outlet like any other household appliance

Unique Dual Rail System

Two parallel and vertical guides bear load of the lift self-supporting structure

Compact Drive System

Housed at the top of the lift, out of sight

Finish: Light grey.
Half-Height Door: The door is interlocked and matches the finish of the elevator.
2 x Remote Controls: Call and send the elevator remotely; also, use it to move heavy
or awkward items between floors.
Two-Year Parts Warranty: All Stiltz Elevators carry a standard 24 months parts warranty.
Internal LED Downlights: Programmed to turn when the user has called or entered the elevator; will remain on for the entire journey.
Battery Back-Up System If there is a power cut while using the elevator, it can be driven to the lower level of the home and will then wait until the power comes back on to resume normal service.
Half-Height Light Curtain: Projects the opening above the half-door from obstructions; the lift will not move until the obstruction has been removed and the light curtain is clear.
Interior Telephone: Help is just a phone call away. Every lift comes standard with a landline phone; a cell phone is available as an option.
Fold-Down Seat: A stylish molded plastic seat is an option; simply lift the seat out of the way when not in use.
Interior Grab Rail: Offers increased security for the occupants of the elevator.
Full-Height Door: An interlocked door that replaces the half-height door option.
Half Height Light Curtain: An obstruction sensor is situated at the entrance of our elevators. If this barrier is crossed at any time, the elevator will immediately stop.
Safety Lid Cover: This crucial feature covers the aperture in the floor when the elevator is in the downstairs position. It is strong enough to stand on, and you can place your original flooring on top to blend in.
Key Switch Operation: This feature allows the owner to lock out the elevator if the need arises. This is commonly used when going away on holiday or when the grandchildren are around.
Top & Bottom Safety Pans: Using our obstruction sensors, a Stiltz elevator can detect objects above or below the elevator, causing it to immediately stop.
Hold-To-Run Controls: Operating a Stiltz Elevator requires constant pressure to the controls. This allows the user to drive the elevator and feel in total control.
Weight Limit Sensors: The Trio Alta home elevator is limited to 500lbs. The elevator detects anything exceeding this limit and will not travel.
Out Of Balance Sensors: Sensors will detect if the elevator is ever out of balance and prevent the unit from travelling.
Fall Arrest Mechanism: This patented system prevents the car from falling in the unlikely event of the steel ropes going slack.
Emergency Stop Button: This button is front and center for the user in the event of an emergency.

Quick and Hassle-Free Installation

Our home elevator can be installed in as little as 1 to 3 days, minimizing disruption and ensuring a convenient transition to enhanced home mobility. The machine room-less design and shallow pit requirement simplify integration into new or existing residential spaces, making this elevator an excellent choice for diverse architectural settings.

Safe and Reliable Operation

Safety is at the forefront, featuring emergency stop functions, overload sensors, automatic rescue devices, and reliable manual lowering in case of emergencies. Battery backup and interlocks further secure smooth and dependable operation, even during power interruptions. The LED indicators and integrated intercom ensure clear communication and status visibility.

Customizable and Energy Efficient

Tailor the elevator to your home's aesthetics with customizable color and finish options, cabin lighting using energy-saving LEDs, and choice of anti-slip flooring. With a modest power draw and efficient drive systems, it delivers performance with lower operational costs, suiting both single-phase and three-phase power supplies.

Versatility and Portability for Modern Homes

Designed for easy relocation and installation, this portable elevator adapts to various residential layouts-including villas, duplexes, and apartments. With a robust capacity for 1-4 persons and a maximum lift height of 12 meters, it offers flexibility without compromising space or structural requirements.

FAQ's of Safe and Portable Home Elevator for Family:

Q: How is the home elevator installed, and how long does the process take?

A: The elevator is designed for rapid and straightforward installation, typically completed within 1 to 3 days. Its machine room-less structure and shallow pit depth of 150 mm allow for integration into existing spaces with minimal structural alterations.

Q: What safety features are included with this portable home elevator?

A: Safety is ensured through multiple features such as emergency stop, overload sensors, interlocks, alarms, battery backup, an automatic rescue device, and manual lowering. These systems provide security during power failures and emergencies, prioritizing family safety.

Q: When is the best time to install this elevator in my residence?

A: This elevator can be installed during new construction or retrofitted into existing homes, apartments, duplexes, and villas. Its compact design and minimal construction requirements make it flexible for both new and already occupied properties.

Q: Where can the elevator be installed within a home?

A: Thanks to its vertical inclination and machine room-less design, the elevator can be placed in indoor settings, such as within stairwells, adjacent to walls, or other appropriately sized spaces that meet the required dimensions (hoistway 1200 x 1300 mm).

Q: What are the main benefits of choosing a portable home elevator?

A: This elevator offers ease of relocation, quick installation, and heightened safety, making it ideal for families seeking a reliable mobility solution that adapts to modern living. It also supports customizable aesthetics and low energy consumption for enhanced convenience.

Q: How does the energy consumption impact daily usage?

A: With power consumption ranging between 1.5 kW and 2.2 kW, the elevator is energy efficient, ensuring sustainable daily use. Energy-saving LED cabin lights and efficient motor drives help reduce operational costs without compromising functionality.

Q: What usage capacities and options does the elevator support?

A: With a load capacity of 250 to 400 kg (1-4 persons) and customizable features such as remote monitoring, integrated intercom, and anti-slip flooring, the elevator accommodates a variety of family needs while maintaining high standards of comfort and performance.
